Pressure Relief Valve
INFORMATION
- MR's Pressure Relief Valve is a spring loaded type for handling over pressure in a various circumstances at the pipe line. Also this valve is to prevent air intake, evaporative lossed of products and help to contain odorous and potentially explosive vapours. Aluminium, Carbon-steel, Stainless Steel with various trims to meet customer's requirement or working conditions. Especially this type can have a balance valve for preventing pressure locking circumstances. Therefore, this valve can operate normal for any unexpected conditions.
- Benefits
- - Minimization of product lossed
- Replaceable seat
- Reduction of emissions
- Excellent flow characteristics
- Maintenance of pressure up to just below the maximum permissible (tank) pressure
- Specification
| Size: |
From 1" (ND 25A) |
To 12" (ND 300A) |
| Pressure Range: |
From 700 mmH2O |
To 10000 mmH2O |
- Materials
| No | Descriptions | Spec. 1 | Spec. 2 | Spec. 3 |
| 1 | Body | A216-WCB | A351-CF8M | B26-319 |
| 2 | Cover | A283-C | A351-CF8M | B26-319 |
| 3 | Disc | A240-304 | A240-316 | A240-304 |
| 4 | Seal | TEFLON | TEFLON | TEFLON |
| 5 | Seat | A351-CF8 | A351-CF8M | A351-CF8 |
- Special materials can available upon request.
